散熱風扇 JHX12025大芯
12025 尺寸/Size 120X120X25mm DC Axial Flow Fan
★Dimensions Drawing(外觀圖） ★Characteristic Curves(特性曲線)
|
★Specifications（規(guī)格） |
|||||||||
|
Model
型號 |
Bearing System 培林 |
Rated Voltage 電壓（V) |
Operation Voltage 電壓范圍 |
Current
電流（A) |
Input Power 功率（W) |
Speed 轉速 （RPM) |
Air Flow 風量 （CFM） |
Static Pressure 靜壓（mm-H2O) |
Noise Level 噪音（dB-A） |
|
JHX12025X12H |
Sleeve Ball |
12 |
10.8~13.2 |
0.50 |
6.0 |
2600 |
85.61 |
4.65 |
41.30 |
|
JHX12025X12M |
0.25 |
3.0 |
2000 |
69.71 |
2.79 |
33.40 |
|||
|
JHX12025X12L |
0.10 |
1.2 |
1500 |
53.35 |
1.81 |
26.20 |
|||
|
JHX12025X24H |
Sleeve Ball |
24 |
21.6～26.4 |
0.30 |
7.2 |
2600 |
85.61 |
4.65 |
41.30 |
|
JHX12025X24M |
0.17 |
4.08 |
2000 |
69.71 |
2.79 |
33.40 |
|||
|
JHX12025X24L |
0.06 |
1.44 |
1500 |
53.35 |
1.81 |
26.20 |
|||
